Processor / System Bus:
1 x Socket LGA1700
Intel® Pentium® Processors
Intel® Xeon® E processors
Intel® Xeon® 6300 series processor
Core Logic: Intel® C262 Chipset
Memory:
Total Slots :
2 (2 Channels)
Capacity :
Maximum up to 64GB
Memory Type :
DDR5 4800/4400/4000/3600 ECC UDIMM
Memory Size :
64GB
* Refer to support page for more information
Expansion Slots:
Total Slot : 1
Slot Location 1 : 1 x PCI-E x16 (x16 Gen5 Link)
Form Factor: Mini ITX (6.7” x 6.7”, 170mm x 170mm)
ASUS Features:
FAN speed control
Rack Ready (Rack and Pedestal dual use)
ASUS Control Cente
Storage:
Storage Controller :
6 x SATA 6Gb/s ports by 4 Mini-SAS HD connectors
1 x M.2 connector(2280,support NVMe PCIe x4 link)
Networking: 2 x Intel® I210-AT2 + 1 x Mgmt LAN
Graphic: Aspeed AST2600 with 64MB VRAM (VGA from BMC)
On Board I/O:
1 x VGA Header (VGA from BMC)
1 x TPM header
1 x COM port
2 x Fan Header , 4pin
1 x Chassis Intruder
2 x Front LAN LED
1 x PSU Power Connector (24-pin ATX power connector + 8-pin ATX 12V power connector)
1 x M.2 Connector
2 x USB 3.2 Gen2 (rear)
2 x USB 3.2 Gen1 (rear)
Back I/O Ports:
2 x USB 3.2 Gen2
2 x USB 3.2 Gen1
1 x VGA port (VGA from BMC)
2 x 1 GbE LAN + 1 x Mgmt LAN
Management Solution: On-Board ASMB11-iKVM for KVM-over-IP
Weight:
Gift Box (1-in-1)
Net Weight : 0.52 KG
Gross Weight : 1.1 KG
Bulk Pack (10-in-1)
Net Weight : 3.66 KG
Gross Weight : 5.8 KG
Environment:
Operation temperature: 10℃ ~ 50℃*
Non operation temperature: -40℃ ~ 70℃
Non operation humidity: 20% ~ 90% ( Non condensing)
*The boundary condition above is based on 8.3W of PCH TDP spec . If the LFM estimate is higher than acceptable value from customer, ASUS can provide boundary condition with raw power for reference.
Accessories:
Gift Box (1-in-1)
1 x I/O shield
1 x Plate for LGA1700
Bulk Pack (10-in-1)
1 x I/O shield
1 x Plate for LGA1700
Monitoring:
CPU Temperature
Fan RPM
